RF Heating Tube End Roll Closing Machine / Metal Steel Pipe End Sealing Machine

¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯

RF Heating Tube End Roll Closing Machine / Metal Steel Pipe End Sealing Machine As Known As Tube End Closing Machine, Sealing Machine, Spinning Machine, Tube Spinning Machine, Tube Closing Machine. Its Used In The Industrial Of Gas Spring, Shock Absorbers, Heat Exchange, Baby Stroller, Kids Tricycle, Baby Playpen, Bicycle, Motorbike, Automobile, Exercise Equipment, Buffer, Gas Lift, Deck Chair, Chaise Lounge, Furniture, Suit Hanger, Lighting Fixtures, House Wares, Sanitary Wares, Recreational Facilities, Rehabilitation and Medical Instruments, Stainless Chopsticks,…Etc.

_________________________________________________________________________

Model:FK-50

Max Capacity:50x1.5mm

Sealing Way:Hot+Rotary Sealing

Drive Mode:Mechanical+Hydraulic/Pneumatic+High Frequency

Business Type:Professoinal Manufacturer

Payment:T/T,L/C,D/P,Western Union,MoneyGram

Lead Time:35Days Dated From Deposit Received

Availability:
Quantity:

x-fk40nc.1.01


RF Heating Tube End Roll Closing Machine / Metal Steel Pipe End Sealing Machine

播放机器视频_副本01



Main Technical Parameters Sheet


参数ch


Brief Introduction on Metal Steel Pipe End Sealing Machine


SLS  RF Heating Tube End Roll Closing Machine / Metal Steel Pipe End Sealing Machine Is a Machine for Closing The Ends of Thin-Walled Copper, Aluminum, Stainless Steel or Steel Tubes. The Tube Is Clamped In a Set of Holding Jaws and Held Stationary and Keep Rotating During Closing. The Principle of The Spinning Machine Is That When The Workpiece Rotates At a High Speed, The Workpiece Is Pressed By a Certain Path Through A Strong External Force, and The Material Is Repeatedly Pressed By The Roller To Make It From Point To Line, and The Line To The Surface Eventually Causes The Workpiece To Be Thermally Deformed. The Shape You Need As On Flat,Semi-Closing or Round Closing. If Need More Information From Us, Contact Us.


x-fk40nc.1.02


Features on Metal Steel Pipe End Sealing Machine


●  Hydraulic System Control The Working Of Machine Movement.

●  Material Available: Carbon Steel, Stainless Steel, Copper...

●  End Close Shape Available: Flat Close, Round Close, Semi-Close

●  High Frequency Heating The Pipe Before End Closing To Improve The Closing Quality

●  Front Positioning To Guarantee The End Closing Requirement On Flat, Semi-Closing or Round Closing.

●  Front Positioning Makes Same End Closing Whether The Pipe Total Length Change or Not.

●  Manual Pipe Loading and Unloading.

●  Automatic High Frequency Heating and Automatic High Frequency Backward.

●  With Function Of Manual, Auto, Emergency To Ensure The High Safety for Operator.

●  Good Mechanical Parts Ensure Machine Runs In High Stability.

●  Easily Operation and Low Nosily



Main Application

x-fk40nc.1.03


Packaging & Shipping

x-sb38cnc.3a-1s.05


Contact Us

x-sb38cnc.4a-1s.07.01
