Professional Terms&Names in Pipe and Tube Bender

Views:0     Author:Site Editor     Publish Time: 2021-07-20      Origin:Site



P1577603-560x270


Cold Tube Bending – The bending of pipe or tube to shapes by cold working methods.

Centerline Radius (CLR) – Distance from the center of curvature to the center line axis of the tube or pipe bends. Often abbreviated as CLR.

Degree – Angle in degrees to which the pipe bends or tube bends are formed (i.e. 45 degrees, 90 degrees, 180 degrees, etc.)

O.D. – Outside diameter of the tube or pipe.

I.D. – Inside diameter of the tube or pipe.

Wall – The thickness of tubular pipe material.

Minimum Tangent – The minimum straight on the end of pipe bends required by the bending machine to form the bend.

Ovality – The distortion or flattening of pipe or tube from its normal, round shape caused by the pipe bending process.

Wrinkles – Waving or corrugation of pipe bends or tube bends in the inner radius.

Easy Way (EZ) – Bending of a rectangular tube with its short side in the plane of the tube bend.

Hard Way (HW) – Bending of a rectangular tube with its long side in the plane of the tube bend.

Tangent – The straight portion of material on either side of arc of rolling bends.

Tangent Point – The point at which the pipe bend or tube bend starts or ends.
